DFL-2100/DFL-2400 Intrusion Detection System User Manual
1
7
gateway:192.168.168.254
CPU utilization: 100%, free memory: 19MBytes
Current TCP connections: 3, TCP idle time limit: 1800 seconds
Maximum log number per second: 500
Detection parameters:
Maximum ping packet size: 100.
VPN bypass: off. TCP state check bypass: off.
WCCP bypass: off. WCCP redirect IP : 0. 0. 0. 0
Remote port: working policy number 861 < on> max ping 100.
Local port: working policy number 861 < on> max ping 100.
$>
get time
Description: Use the get time command to display the time information of DFL-
2100/DFL-2400
Syntax: get time
Arguments: none
Example:
>>get time
Boot time: Thu Apr 11 15:21:35 2002 GMT +8.
Now time : Thu Apr 11 17:28:39 2002 GMT +8.
Up time : 0 days, 2 hours, 7 minutes, 4 seconds.
>>
get log
Description: Use the get log command to display the log information of DFL-2100/DFL-
2400
Syntax: get log
Arguments: none
Example:
>>get log
2002/05/16 19:53:05 U:SYS:Failed to open DDoS policy file!
2002/05/16 19:53:05 U:SYS:Failed to open policy file!
2002/05/16 19:53:05 I:SYS:DFL-2100/DFL-2400 startup!
2002/05/16 19:53:44 I:CON:Login OK!
2002/05/16 19:55:12 I:SSH:SSH user login from 192.168.168.65 OK!
-------------------------------------------------------------------------------
Event level => I :Info, W : Warning, U : Urgent, F : Fatal
Event source => CON : Console, SSH : SSH, SYS : System, PSS : Policy agent.
