DFL-2100/DFL-2400 Intrusion Detection System User Manual
1
5
psserver - Policy server configurations.
snmp - snmp parameters.
>>
help ping
Description: Use the help ping command to display the arguments of “ping command”
Syntax: help ping
Arguments: none
Example:
>>help ping
ping - Ping utility
>>
help arp
Description: Use the help arp command to display the arguments of “arp command”
Syntax: help arp
Arguments: none
Example:
>>help arp
arp - Show & handle arp table.
>>
help netstat
Description: Use the help netstat command to display the arguments of “netstat
command”
Syntax: help netstat
Arguments: none
Example:
>>help netstat
netstat- Show system network status.
help reset
Description: Use the help reset command to display the arguments of “reset command”
Syntax: help reset
Arguments: none
Example:
>>help reset
reset - Reset system configurations to manufacturing defaults.
