DFL-2100/DFL-2400 Intrusion Detection System User Manual
21
Need value: 10 - 10000
>>set sys logmax 300
Change max log OK.
set system detect
Description: Use the set system detect command to configure DFL-2100/DFL-2400
intrusion detect parameters
Syntax: get system detect [tcptimeout|policy|pingmax|stateful | integrity | pinglen | wccp |
vpnbypass ] [ ip | gateway | mask | passwd | rpasswd | detect | logmax ]
Arguments:
tpctimeout <Value: 20-86400> Set and modify the TCP connections timeout
policy <remote|local> <on|off> Set and modify the policies work or not.
pingmax <remote|local> <Value:1-5000>
Allow how many users can ping a host in a
second
stateful <on|off> Checking the TCP state or not. Default setting is
<off>.
integrity <on|off> Checking the IP integrity or not. Default setting
is <on>
pinglen <Value: 64-1500> Set and modify the packet size of ping
wccp < bypass | redirect_ip > Checking the WCCP packet or not , and
specification the redirect host IP address.
vpnbypass < on | off > Checking the VPN packet or not
Example:
Ex 1:
>>set system detect tcptimeout
Need value: 20-86400
>>set system detect tcptimeout 6000
Change TCP session time out limit to 6000 OK.
>>
Ex 2:
>>set system detect pingmax local
Need value : 1-5000
>>set system detect pingmax remote 3000
Change remote port maximum ping packet limit to 3000 OK.
Ex 3:
>>set system detect policy remote on
Apply policy check for remote interface OK.
>>
set time
Description: Use the set time command to set the system time on the DFL-2100/DFL-
2400 Device
Syntax: set time
Arguments: none
Example:
