DFL-2100/DFL-2400 Intrusion Detection System User Manual
29
4
4 IDS MANAGEMENT SYSTEM
DFL-2100/DFL-2400 Management System is a Web-based application that
allows multi user to manage one or more DFL-2100/DFL-2400 devices concurrently.
It can be used from any computer with access to the DFL-2100/DFL-2400 Policy
Server via Web browser.
DFL-2100/2400 IDS Management Main Screen
Login
Connect the DFL-2100/DFL-2400 Policy Server from browser
¾ Open your browser, and enter:
http://<IP Address of the Policy Server>:6592/IDS/
1. Select Manager from the Policy Server web homepage, the following login dialog will
appear.
2. Enter the Password and click Login to login to the DFL-2100/ DFL-2400 Management
System.
(Default ID: admin; Password : admin)
Note: The control mechanism of access to DFL-2100/DFL-2400 IDS Management System
is password.
Figure 4-1: DFL-2100/DFL-2400 Management System Login Screen
