DFL-2100/DFL-2400 Intrusion Detection System User Manual
14
The Command Classes
All Commands are divided into four classes, Help, Query, Set, and Miscellaneous.
The Commands in the ‘Help’ class are used to give user other command’s information. The
Commands in the ‘Query’ class are used by prefix command ‘get’ to retrieval system
information and configuration. And the Commands in ‘Set’ class are used by prefix command
‘set’ to given parameters for system. Other functions not belonged to above two classes are
in the ‘Miscellaneous’ class.
Help Command
The get command can display the arguments of others.
help get
Description: Use the help get command to display the arguments of “get command”
Syntax: help get
Arguments: none
Example:
>>help get
get - Get system information. Available commands:
system - System configurations, including IP, password and etc.
log - System logs.
time - Device clock setting.
interface - Interface stealth function and working link mode.
state - Device operation state.
psserver - Policy server configurations.
snmp - snmp parameters.
help set
Description: Use the help set command to display the arguments of “set command”
Syntax: help set
Arguments: none
Example:
>>help set
set - Set system parameters. Available commands:
system - System configurations, including IP, password and etc.
time - Device clock setting.
interface - Interface stealth function and working link mode.
state - Device operation state.
