DFL-2100/DFL-2400 Intrusion Detection System User Manual
2
6
Trap<enable | disable | ip> Enable or disable SNMP traps for the
community. Define the IP address listen
the trap.
Example:
>>set snmp trap
Need command: [ enable | disable | ip ]
>>
>>set snmp trap ip 192.168.168.65
Add SNMP Trap IP OK
Note 1. This command is only applicable to console.
Miscellaneous Commands
ping
Description: Use the ping command to check the network connection to another system
Syntax: ping [host_ip] [timeout] [count]
Arguments:
host_ip Ping the host with IP address
timeout The ping timeout in seconds
count The ping count
Example:
>>ping 192.168.168.65
ping (192.168.168.65): 56 data bytes
192.168.168.65 is alive
>>ping -s 192.168.168.165 10
ping (192.168.168.165): 56 data bytes
64 bytes from 192.168.168.165: icmp_seq=0
64 bytes from 192.168.168.165: icmp_seq=1
64 bytes from 192.168.168.165: icmp_seq=2
64 bytes from 192.168.168.165: icmp_seq=3
64 bytes from 192.168.168.165: icmp_seq=4
64 bytes from 192.168.168.165: icmp_seq=5
64 bytes from 192.168.168.165: icmp_seq=6
64 bytes from 192.168.168.165: icmp_seq=7
64 bytes from 192.168.168.165: icmp_seq=8
64 bytes from 192.168.168.165: icmp_seq=9
10 packets transmitted, 10 packets received
>>
