D-Link DFL-2400 [88/112] Real time network attack monitor

DFL-2100/DFL-2400 Intrusion Detection System User Manual

Real-time network attack monitor

The on-line “Real-time network attack monitor” of DFL-2100/ DFL-2400

IDS Reporting System provides real-time warnings of network attacks in the form of text.

For the system manager to fully understand the current situation of network at a glance, the

monitoring function classifies the threatening levels of network attacks into 5 real-time

monitoring screens - serious threat, high-level threat, medium-level threat, low-level threat

and slight threat.

Figure 8-2: On-line real-time monitoring network attack

Figure 8-3: Enlarge and narrow the real-time monitoring screen of network attack
