DFL-2100/DFL-2400 Intrusion Detection System User Manual
2
7
arp
Description: Use the arp command display the entries in the Address Resolution Protocol
table
Syntax: arp [-a|-d host]
Arguments:
-a Show the all ARP table entries
-d Delete the host IP address in ARP table
host Show the host IP address in ARP table
Example:
>>arp
usage: arp host
arp -a
arp -d host
arp -s host ether_addr [temp]
arp -f filename
>>arp 192.168.168.65
192.168.168.65 (192.168.168.65) at 0:0:e2:65:94:7d
>>arp -a
192.168.168.65 (192.168.168.65) at 0:0:e2:65:94:7d
192.168.168.70 (192.168.168.70) at 0:50:fc:2f:d3:6a
192.168.168.165 (192.168.168.165) at 0:50:ba:1a:9b:ab
192.168.168.254 (192.168.168.254) at 0:7:4f:d:60:1c
192.168.168.71 (192.168.168.71) at 0:50:22:0:38:27
>>
netstat
Description: Use the netstat command display the network status for debug
Syntax: netstat [-a]
Arguments:
-a Show the network connected status,
include the protocol, host IP, state.
Example:
>>netstat -a
Proto Local Address Foreign Address (state)
udp 0.0.0.0.199
udp 0.0.0.0.1024
udp 0.0.0.0.161
tcp 127.0.0.1.1024 127.0.0.1.9728 ESTABLISHED
tcp 127.0.0.1.9728 127.0.0.1.1024 ESTABLISHED
tcp 0.0.0.0.7594 0.0.0.0.0 LISTEN
tcp 192.168.168.201.22 192.168.168.65.2455 ESTABLISHED
