DFL-2100/DFL-2400 Intrusion Detection System User Manual
3
2
Remove a DFL-2100/DFL-2400
1. Select the DFL-2100/DFL-2400 you want to remove from the IDS Tree.
2. Click Remove DFL-2100/DFL-2400 button
on the tool bar or right-click on the tree
and select “Remove” from the pop-up menu. A warning message is displayed.
3. Click “Yes” to remove this DFL-2100/DFL-2400 from the IDS Tree, or “No” to cancel this
action.
Modify a DFL-2100/DFL-2400
1. Click Modify DFL-2100/DFL-2400 button or right-click on the IDS tree window to
bring up the pop-up menu. Select Modify DFL-2100/DFL-2400.
2. Enter the new Alias Name of the DFL-2100/DFL-2400.
3. Click “Modify” to update the property of this DFL-2100/DFL-2400 or “Cancel” to cancel
the modification.
Figure 4-5:”Modify this DFL-2100/DFL-2400” Dialog
Note Remove DFL-2100/DFL-2400 will also remove all the log files from
the Policy Server. If you wish to keep these log files, backup these
files on the Policy Server before removing this DFL-2100/DFL-
2400.
