DFL-2100/DFL-2400 Intrusion Detection System User Manual
23
half Setting the physical connection operate mode at
half duplex
Example:
>>set interface link
Need interface name : [remote | local | manage ]
Note This command is only applicable to console.
set interface stealth
Description: Use the set interface stealth command to set the stealth mode on the
specified interface on the DFL-2100/DFL-2400 Device
Syntax: set interface stealth [remote|local|manage]
Arguments:
<remote|local|manage>
remote Specified remote(WAN) interface setting
local Specified local(LAN) interface setting
manage Specified manage interface setting
Example:
>>set interface stealth remote
Need interface name: [ remote | local | manage ]
Note 1. This command is only applicable to console
set psserver
Description: Use the set psserver command to configure the Policy Server, which
manage and log events for the DFL-2100/DFL-2400 Device
Syntax: set psserver [ip|interval]
Arguments:
ip <ip_address> Set the Policy Server host IP
interval <value:10-600> Configure the time interval of sending the
events to the Policy Server.
Note: If Policy Server set behind the firewall, the IP address shouldn’t the IP address of
“real Policy Server”. Please check your network status before you enter the IP
address.
Example:
For example, A DFL-2100/DFL-2400 on the network 192.168.168.xxx and the Policy
Server set behind the firewall at 10.0.0.xxx. The firewall or NAT must
reconfigure a Virtual IP or Mapped IP for Policy Server. The DFL-2100/DFL-
2400 set the Policy Server IP to the Virtual IP.
