Dc Inverter VRF plus Water Heater Solution Service Manual CONTROL
98
wired controller
5.2 Operation View
（Fig.5.2）
Instruction to functions of buttons (Table 5.1)
No. Name Function
1
FUNC
(FUNCTION
)
A. Switch the control mode of inquiry/single/ central control.
B. In central control status, give the central order by successively pressing
FUNC button.
2 MODE Set cooling/heating/fan/dry mode for indoor unit
3 ▲
A. Inquiry status: cycle, increase or decrease No. of indoor units to easily
inquire the status of each indoor unit.
B. Single/Central control status: set running temp. of indoor unit, maximum is
30 and minimum is 16 .℃℃
C. Timer setting status: increase or decrease the timer on/off time, maximum
is 24hr and minimum is 0.
4 ▼
5 FAN
A. Set the indoor fan speed of hi/mid/low/auto.
B. Successively press FAN button to set on/off swing.
6 TIMER
A． Under single/central control mode, set on /off timer of selected indoor unit
B． Under inquiry status, inquire the timer setting of the indoor unit with current
address.
7 ON/OFF Set ON/OFF of the indoor unit.
2MODE and
7 ON/OFF
Lock
Under single/central control, press MODE and ON/OFF buttons
simultaneously to start/ stop the lock of operation to buttons of wired controller
for selected indoor units.
2MODE and
6 TIMER
Shield mode
Under single/central control, press MODE and TIMER simultaneously to start/
stop the shield of operation to MODE button of wired controller for selected
indoor unit.
4 ▼and
6 TIMER
Shielding
Temp.
Under single/central control, press ▼ and TIMER simultaneously to start/ stop
the shield of operation to Temp button of wired controller for selected indoor
unit.
7 ON/OFF
and
6 TIMER
Shielding
ON/OFF
Under single/central control, press ON/OFF and TIMER simultaneously to
start/ stop the shield of operation to ON/OFF button of wired controller for
selected indoor unit.
2 MODE
and 3 ▲
Memory
mode
Refer to power-off memory function about the details.
4 ▼and
7 ON/OFF
Selection
of function
A．Check the control mode of region monitoring controller / region wired
controller
B．Set the control mode of region monitoring controller / region wired controller
Note:
① The characters with gray back ground indicate buttons. Following part is the same to it.
② The time of single press of the button is more than 3s, which means successively-press.
③ There isn‘t the function that the region wired controller shields other indoor wired controller.
