Dc Inverter VRF plus Water Heater Solution Service Manual INSTALLATION
150
6.2.2 Dimensions Data
GMV(L)-R28T/Na-K, GMV(L)-R36T/Na-K, GMV(L)-R45T/Na-K, GMV(L)-R50T/Na-K,
GMV(L)-R56T/Na-K, GMV(L)-R63T/Na-K, GMV(L)-R71T/Na-K, GMV(L)-R80T/Na-K,
GMV(L)-R90T/Na-K, GMV(L)-R100T/Na-K, GMV(L)-R112T/Na-K, GMV(L)-R140T/Na-K.
Package
Dimension
Model
Width (mm) Depth (mm) Height (mm)
GMV(L)-R28T/Na-K 950 950 210
GMV(L)-R36T/Na-K 950 950 210
GMV(L)-R45T/Na-K 950 950 210
GMV(L)-R50T/Na-K 950 950 210
GMV(L)-R56T/Na-K 950 950 310
GMV(L)-R63T/Na-K 950 950 310
GMV(L)-R71T/Na-K 950 950 310
GMV(L)-R80T/Na-K 950 950 310
GMV(L)-R90T/Na-K 950 950 340
GMV(L)-R100T/Na-K 950 950 340
GMV(L)-R112T/Na-K 950 950 340
GMV(L)-R125T/Na-K 950 950 340
GMV(L)-R140T/Na-K 950 950 340
GMV(L)-R22T/NaA-K 650 650 230
GMV(L)-R28T/NaA-K 650 650 230
GMV(L)-R36T/NaA-K 650 650 230
GMV(L)-R45T/NaA-K 650 650 230
