Dc Inverter VRF plus Water Heater Solution Service Manual INSTALLATION
134
（
（
）
）
Skecth map of installation D（with solar,floor heater and water tank）
Diagram D Model of Hydro-box
Recommended water
tank
GMV-Pds224W/Na RQD20LA-M
SXVD350LCJ2/A-K or
SXVD400LCJ2/A-K
GMV-Pds280W/Na-M RQD30LA-M-M
SXVD350LCJ2/A-K or
SXVD400LCJ2/A-K
Ducted
