7.3 Connecting Pipe between Outdoor Unit and Hydro-box
Connect outdoor unit with hydro-box by refrigerants piping
Model
Refrigerants
Pipe
Diameter (mm) Length≤d（m） Connection way
RQD5GA-K
RQD8GA-K
RQD8GB-K
RQD5GB-K
RQ8GB-K
RQ5GB-K
Gas pipe 15.9 10 Negative Delta
Liquid pipe 12.7 10 Negative Delta
RQ20LA-K
RQ30LA-K
RQD20LA-M
RQD30LA-M
Gas pipe 19.05 10 Negative Delta
Liquid pipe 15.9 10 Negative Delta
7.4 Connection Requirements of Hydro-box and Water Tank
Connect hydro-box with water tank by water pipe which can be galvanized pipe or seamless steel pipe,like
PVC pipe, PPR pipe, etc.
Circulating Pipe Joint Size（in）
Vertical Height≤d
（m）
Connection Method
Inlet Pipe 3/4" 3
Threaded
Connection
Outlet Pipe 3/4" 3
Threaded
Connection
☆ If the vertical height is more than 5m, please contact us.
☆ Execute insulation work to circulating tube and the thickness of heat insulating material shall be not less than
10mm.
☆ Each joint of circulating tube shall be completely sealed.
