2 NOMENCLATURE
2.1 Nomenclature of outdoor unit
GMV □ □ - Pds 120 W / Na - K
1 2 3 4 5 6 7 8
NO. Description Options
1 Code for type GMV=Gree Multi Variable
2 Code for weather Default:T1 T2:T2 weather T3:T3 weather
3 Code for model
L: Cooling Only
Default: Heat pump
4 Units Series
Pd: DC inverter VRF
Pds: DC inverter VRF with water heating
5 Nominal cooling capacity
120 represents 12kW
Btu/h=kW×3412
6 W: outdoor unit
7 Refrigerant Na: R410A
8 Power supply
K: 220-240V-1Ph-50Hz
M: 380-415V-3Ph-50Hz
2.2 Nomenclature of indoor unit
GMV □ - R □ □ / Na □ - □
1 2 3 4 5 6 7 8
NO. Description Options
1
Code for type GMV=Gree Multi Variable
2 Model Code
L: Cooling Only
Default: Heat pump
3
Code for weather Default:T1 T2:T2 weather T3:T3 weather
4 Nominal cooling capacity
36 represents 3.6kW Btu/h=kW×3412
5
Code for unit type
P=Duct type
T=Cassette type
Td=1-way Casstte type
G=Wall mounted
Zd=Floor ceiling
6 Refrigerant: R410A
7 Design Sequence. B :Second generation
8 Power complement M: 380-415V-3Ph-50Hz； K ：220-240V-1Ph-50Hz
Example: GMV-R22G/NaB-K. A wall mounted indoor unit of GREE, and the nominal cooling
capacity is 2.2kw. It's the second generation product。
