Dc Inverter VRF plus Water Heater Solution Service Manual INSTALLATION
166
7 INSTALLATION OF HYDRO-BOX
7.1 Dimension of Hydro-box
Applicable to RQD8GA-K、RQD5GA-K、RQ8GB-K、RQ5GB-K
Dimension（mm）（W×D×H） 650×300×250
Power Specification 220V 50Hz~
Dimension of Pipe
Refrigerants
Liquid
pipe
mm Φ12.7
Gas Pipe mm Φ15.9
Water
Feed pipe in 3/4"
Discharge
pipe
in 3/4"
Applicable to RQD8GB-K、RQD5GB-K
Dimension（mm）（W×D×H） 650×435×258
Power Specification 220V 50Hz~
Dimension of Pipe
Refrigerants
Liquid
pipe
mm Φ12.7
Gas Pipe mm Φ15.9
Water
Feed pipe in 3/4"
Discharge
pipe
in 3/4"
Applicable to RQ20LA-K.RQ30LA-K
Dimension（mm）（W×D×H） 1050×410×905
Power Specification 220V 50Hz~
Dimension of Pipe
Refrigerants
Liquid
pipe
mm
Φ19.05
Gas Pipe mm Φ15.9
Water
Feed pipe in 3/4"
Discharge
pipe
in 3/4"
Applicable to RQD20LA-M.RQD30LA-M.
Dimension（mm）（W×D×H） 1050×410×905
Power Specification 380V 50Hz~
Dimension of Pipe
Refrigerants
Liquid
pipe
mm Φ19.05
Gas Pipe mm Φ15.9
Water
Feed pipe in 3/4"
Discharge
pipe
in 3/4"
7.2 Installation Method and Dimension of Hydro-box
7.2.1 Applicable to RQD8GA-K.RQD5GA-K. RQD8GB-K.RQD5GB-K. RQ8GB-K.RQ5GB-K.
Floor standing, wall mounting and ceiling mounting are permissible. For wall mounting, take care
that the motor of water pump shall not be upright.
Correct Wall-mounted Installation:
