Dc Inverter VRF plus Water Heater Solution Service Manual INSTALLATION
131
Installation Schematics B
single pipe heat
exchanger for Solar
single pipe heat
exchanger for
Hydro unit
Circulating In
Circulating Out
Circulating In
Circulating Out
Cold water in
Temperature
sensor hole
1
Water Temperature Sensor 2
Temperature
sensor hole
2
Sewage Port
Cutoff Valve
Faucet Water
Cutoff Valve
(Normally Open)
Filter
Check Valve
Hot Water Out
Cutoff Valve
Cutoff Valve "A"
Manual
Vent
Valve B
Temperature
sensor
Water Inlet
Water outlet
Manual Vent Valve A
Hydro indoor unit for DC
inverter VRF water
heater
Earthing Wire of Water Tank
Hot water out
Auxiliary
electric
heating
Auxiliary Electric Heating
Power Cable
Automatic
Vent Valve
pressure water tank
(with signle pipe heat exchanger in)
Installation Schematics C
4.2 Installation Schematic Diagram of Units with Top Air Outlet
A.B.C.D.D The diagrams below are applicable to GMV-Pds224W/Na 和 GMV-Pds280W/Na equipped with
RQD20LA.RQD30LA.RQ20LA.RQ30LA.
（
）
（
）
