4.5 Water Tank
Model SXD250LC-K SXD300LC-K SXD350LC-K SXD400LC-K
Capacity V 250 300 350 400
Max.Working Pressure MPa 0.7 0.7 0.7 0.7
Inner pot
Material - SUS304L SUS304L SUS304L SUS304L
Thickness mm 1.5 1.5 1.5 1.5
Insulating
Layer
Material - Polyurethane Polyurethane Polyurethane Polyurethane
Thickness mm 50 45 45 45
Outer Layer
Material - Cold Plate Cold Plate Cold Plate Cold Plate
Thickness mm 0.8 0.8 0.8 0.8
Circulated
Pipes
Caliber mm DN20 DN20 DN20 DN20
Screw
Thread
- G3/4 G3/4 G3/4 G3/4
Cool Water-in
Pipe
Caliber mm DN15 DN15 DN15 DN15
Screw
Thread
- G1/2 G1/2 G1/2 G1/2
Hot Water-out
Pipe
Caliber mm DN15 DN15 DN15 DN15
Screw
Thread
- G1/2 G1/2 G1/2 G1/2
Dimension
Outer
Diameter
×Height
mm Φ540×1945 Φ620×1620 Φ620×1895 Φ620×2125
Net Weight/Gross Weight kg 68/77 71/81 79/90 86/98
Pile Layer - 3 3 3 3
Model SXD200LCJ/A-K SXD300LCJ/A-K
SXD350LCJ/A-
K
SXD400LCJ/A-
K
Capacity V 200 300 350 400
Max.Working Pressure MPa 0.7 0.7 0.7 0.7
Inner pot
Material - SUS304L SUS304L SUS304L SUS304L
Thickness mm 1.5 1.5 1.5 1.5
Insulating
Layer
Material - Polyurethane Polyurethane Polyurethane Polyurethane
Thickness mm 50 45 45 45
Outer
Layer
Material - Cold Plate Cold Plate Cold Plate Cold Plate
Thickness mm 0.8 0.8 0.8 0.8
Circulated
Pipes
Caliber mm DN20 DN20 DN20 DN20
Screw
Thread
- G3/4 G3/4 G3/4 G3/4
Cool
Water-in
Pipe
Caliber mm DN15 DN15 DN15 DN15
Screw
Thread
- G1/2 G1/2 G1/2 G1/2
Hot
Water-out
Pipe
Caliber mm DN15 DN15 DN15 DN15
Screw
Thread
- G1/2 G1/2 G1/2 G1/2
Dimension
Outer
Diameter
×Height
mm Φ540×1595 Φ620×1620 Φ620×1895 Φ620×2125
Net Weight/Gross
Weight
kg 68/80 84/94 92/103 99/111
Pile Layer - 3 3 3 3
