Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
27
4.2.2Cassete Type
Model
GMV (L)-
R22T/NaA-K
GMV(L)-
R28T/NaA-K
GMV(L)-
R36T/NaA-K
GMV(L)-
R45T/NaA-K
Cooling Capacity
kW 2.2 2.8 3.6 4.5
Btu 7506 9554 12283 15354
Heating Capacity
kW 2.5 3.2 4.0 5.0
Btu 8530 10918 13648 17060
Air Flow Rate
m3/h 600 600 600 600
CFM 353 353 353 353
Sound Pressure Level (H/L) dB(A) 47/41 47/41 47/41 47/41
Power Supply
220-240V-1Ph-5
0Hz
220-240V-1Ph-
50Hz
220-240V-1Ph
-50Hz
220-240V-1P
h-50Hz
Fan Motor
Output kW 0.011 0.011 0.011 0.011
Running
Current
A 0.05 0.05 0.05 0.05
Connecting
Pipes
Gas Pipe
mm
Φ9.52 Φ12.7
inch
3/8＂ 1/2＂
Liquid Pipe
mm
Φ6.35 Φ6.35
inch
1/4＂ 1/4＂
Connection Method Flare Connection Flare Connection
Drain Pipes
(External Dia. × Thickness)
mm
Φ30×1.5
Unit Dimensions
(W×D×H)
mm
Main body：570×570×230 Panel：650×650×50
Package Dimensions
(W×D×H)
mm
Main body：848×728×310 Panel：730×670×102
Weight(Net/ Gross)
(Main body/Panel)
kg 25/37
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the cooling only
units dose not have any parameters of performing heating;
③ The sound level was tested under circumstance of semi-anechoic chamber; the value of noise could be a little higher in
actual operation.
