Dc Inverter VRF plus Water Heater Solution Service Manual MAINTENANCE
221
1）Disassemble the front panel of outdoor unit
2） There is a drain on side Tube in tube which is on lower part of the front. Unscrew the cap of the drain to drain
water.
Front
panel
Drain screw cap
