Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
349
No. Part Name
GMV(L)-R71G/Na-K
；GMV(L)-R80G/Na-K
Code Qty.
1 Wall-Mounting Frame
01252398
1
2 Rear Case
22202091
1
3 Fan Bearing
76512203
1
4 Screw Cover
242520053
3
5 Swing Louver
10512110
15
6 Swing Link
10582040
3
7 Water Tray
20182043
1
8 Guide Louver（up）
10512062
1
9 Guide Louver（down）
10512063
1
10 Cross Flow Fan
10352420
1
11 Evaporator Assy
0102411202
1
12 Drainage hose
0523001404
1
13 Evaporator Support（left）
24212041
1
14 Filter
11122051
2
15 Front Case
26904107
1
16 Front Panel
20002698
1
17 Front Panel A
22432258
1
18 Remote Controller Y512
305125063
1
19 Receiver Board JD
30046093
1
20 Electric Box Cover
20102252
1
21 Switch Lever
10582007
1
22 Wire Clamp
71010103
1
23 Terminal Board T4B3A
42011233
1
24 Electric Box Cover
201022513
1
25 Main PCB 30226420
1
26 Transformer 48X26G 43110233 1
27 Room Sensor 3900019813 1
28 Tube Sensor
3900019814 1
3900019815 1
3900019816 1
29
Sensor Insert
42020063
3
30 Electric Box
20102250
1
31
Lower Shield of Electric Box
01592034
1
32
Upper Shield of Electric Box
01592033
1
33 Stepping Motor MP24GA
15212102
1
34 Evaporator Support（rihgt）
24212042
1
35 Motor Clamp
26112069
1
36
Motor FN26D
150121053
1
37
Fixer(evaporator)
02112009
1
38 Pipe Clamp
26112071
1
39
Signal Cable
400103953
1
40 Fix sub-assy
01324110P
1
41 EXV sub-assy
07334255
1
42
Connecting Wire
40010267 1
