Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
15
4.2 Product Data of Indoor Unit
4.2.1 Duct Type
Model GMV(L)-R22P/Na-K GMV(L)-R25P/Na-K GMV(L)-R28P/Na-K
Cooling Capacity
kW 2.2 2.5 2.8
Btu 7506 8530 9554
Heating Capacity
kW 2.5 3.0 3.2
Btu 8530 10236 10918
Air Flow Rate
m3/h 450 450 570
CFM 265 265 336
Sound Pressure Level (H/L) dB(A) 37/33 37/33 39/35
External Static Pressure Pa 25 25 25
Power Supply 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz
Fan Motor
Output kW 0.02 0.02 0.02
Running
Current
A 0.17 0.17 0.16
Connectin
g Pipes
Gas Pipe
mm
φ9.52
φ9.52 φ9.52
inch
φ3/8＂
φ3/8＂ φ3/8＂
Liquid Pipe
mm φ6.35 φ6.35
φ6.35
inch
φ1/4＂
φ1/4＂
φ1/4＂
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
（External Dia. × Thickness）
mm φ20×1.5 φ20×1.5 φ20×1.5
Unit Dimensions(W×D×H) mm 875×680×220 875×680×220 875×680×220
Package Dimensions
(W×D×H)
mm 1012×708×275 1012×708×275 1012×708×275
Weight（Net/Gross） kg 27/31 27/31 27/31
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the
cooling only units does not have any parameters of performing heating;
③ The sound level is tested under circumstance of semi-anechoic chamber; the value of noise could be a
little higher in actual operation.
