Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
16
Model GMV(L)-R32P/Na-K GMV(L)-R36P/Na-K
GMV(L)-R40P/Na-
K
Cooling Capacity
kW 3.2 3.6 4.0
Btu 10919 12284 13649
Heating Capacity
kW 3.6 4.0 4.5
Btu 12283 13648 15354
Air Flow Rate
m3/h 570 570 840
CFM 336 336 494
Sound Pressure Level (H/L) dB(A) 39/35 39/35 40/36
External Static Pressure Pa 25 25 20
Power Supply 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz
220-240V-1Ph-50H
z
Fan Motor
Output kW 0.02 0.02 0.07
Running
Current
A 0.16 0.16 0.69
Connectin
g Pipes
Gas Pipe
mm φ12.7 φ12.7
φ12.7
inch
φ1/2＂ φ1/2＂
φ1/2＂
Liquid Pipe
mm
φ6.35 φ6.35 φ6.35
inch
φ1/4＂ φ1/4＂ φ1/4＂
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
（External Dia. × Thickness）
mm φ20×1.5 φ20×1.5 φ30×1.5
Unit Dimensions(W×D×H) mm 875×680×220 875×680×220 980×736×266
Package Dimensions
(W×D×H)
mm 1012×708×275 1012×708×275 1068×766×320
Weight（Net/Gross） kg 27/31 27/31 36/39
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the
cooling only units does not have any parameters of performing heating;
③ The sound level is tested under circumstance of semi-anechoic chamber; the value of noise could be a
little higher in actual operation.
