Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
351
No. Part Name
GMV(L)-R22G/NaC-K；GMV(L)-R28G/NaC-K
Code Qty.
1
Wall Mounting Frame 01252220 1
2
Rear Case 222020012 1
3
Evaporator Assy 01004628 1
4
Cross Flow Fan 10352001 1
5
O-Gasket of Cross Fan Bearing 76512203 1
6
Drain Pipe 0523001401 1
7
Water Tray 201820272 1
8
Air Louver 10512080 1
9
Swing Lever 10582002 1
10
Swing Lever 10582003 1
11
Front Case 200024442 1
12
Screw Cap 24252006 3
13
Filter 11122002 2
14
Remote Control Y512 305125063 1
15
Display Board 30545707 1
16
Front Panel 20002522 1
17
Guide Louver 10512034 1
18
Guide Louver 10512033 1
19
Stepping Motor 15212110 1
20
Motor Press Plate 26112014 1
21
Fan Motor 150121081 1
22
Electric Box Cover 22242030 1
23
4-bit Terminal Board 42011233 1
24
Electric Box Cover 201220061 1
25
Electric Box 20102178 1
26
Main PCB Z6H251B 30226077 1
27
Transformer 43110226 1
28
Fixed Clamp 71010103 1
29
Pipe Clamp 24242001 1
30
Connecting Wire（communicate)
400103953 1
