Dc Inverter VRF plus Water Heater Solution Service Manual INSTALLATION
213
Rated heating capacity of
water tank coil is default
value of capacity of cap
jumper(kW)
Setting on
wired
controller of
water tank
Rated heating capacity
of water tank coil is
default value of capacity
of cap jumper(kW)
Setting on wired
controller of water tank
5 5 40 40
8 8 45 45
12 12 reserved reserved
15 15
reserved reserved
20 20
reserved reserved
25 25
reserved reserved
30 30
reserved reserved
35 35
reserved reserved
Note: when setting the value above on wired controller, the options will be displayed circularly
and its unit is KW.
14.4.2 Setting of Capacity of Outdoor Unit
The setting of capacity of outdoor unit is determined by the cap jumper of outdoor unit. Different
cap jumpers represent different capacities of water tank as shown in the table below:
Rated Capacity of Outdoor Unit No. of Cap Jumper
100 No.9 Cap Jumper
120 No.8 Cap Jumper
140 No.7 Cap Jumper
160 No.11 Cap Jumper
