Gree HOME GMV [231/367] Flow chart of troubleshooting
![Gree HOME GMV [231/367] Flow chart of troubleshooting](/views2/1052459/page231/bge7.png)
Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
227
2 FLOW CHART OF TROUBLESHOOTING
2.1 High-pressure protection
高压保护
用压力表
测量其压力是否为
真正高压？
检查
室内机运行模式设定
是否恰当？
检查
大小阀门是否完全
打开？
检查室外
机面板是否盖上
封严？
检查室内、
外机换热器进出风
是否顺利？
检查
室内、外机风机是否
运行？
检查室内
扫风叶片是否完全
打开？
检查室外机
容量输出与室内机容
量需求相同？
检查室内
电子膨胀阀动作是否
正常？
检查室内外
过滤网或换热翅片是
否有脏堵？
系统管路有堵塞
参照维修与保养
使阀体和线圈啮合
参照室内外机拨码
测量扫风电机和信
号输入情况
测量风机电机和信
号输入情况
清除障碍物
盖好面板
完全打开阀门
参照室内机说明书
测量
压力开关是否
正常？
更换室外机主板
更换压力开关
是
主要检查各室内机与主管连接的进出口，还有室内、外机的电子膨胀
阀等处。更换电子膨胀阀、干燥过滤器等零件。
否
否
否
否
否
否
否
否
否
是否
是
是
是
是
是
是
是
是
是
否
Remove the obstructions
Measure the fan motor and
signal input
Measure the swing motor and
signal input
Refer to the dial-up of indoor and outdoor unit
Engage the valve body with the coil
Refer to the Repair and Maintenance
The system pipe is blocked
Focus on checking the inlet and outlet of the connection between indoor units and main
pipe. Also focus on checking the electronic expansion valve of indoor unit and outdoo
r
unit. Replace the electronic expansion valve, drying filter and other parts
Check if the air inlet and outlet
of the indoor and outdoor
exchanger is smooth?
Check if the indoor
and outdoor fans run
normally?
Check if the indoor
swing louver is fully
open?
Check if the capacity output of
outdoor unit is equal to the
capacity demand of indoor
units?
Check if the indoor
electronic expansion valve
can work normally
Check if the indoor /
outdoor filters or radiating
fins are dirty or blocked?
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
No
No
Cover up the front panel properly
Check if the front panel of
outdoor unit is covered
tightly?
No
Yes
Fully open the valve
Replace the pressure switch
Refer to the Instruction Manual for
Indoor Unit
Replace the mainboard of outdoor unit
High-pressure protection
Use pressure gauge to
measure if the pressure is
really high?
Measure if the
pressure switch is
normal？
Check if the operation
mode of indoor unit is
set properly?
Check if the gas valve
and liquid valve are
fully open?
No
No
No
No
Yes
Yes
Yes
Yes
