Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
9
1.2.7Floor ceiling type
Model
Capacity
Ref
Power
Supply
Appearance
Cooling
(Btu/h)
Heating
(Btu/h)
GMV-R28Zd/Na-K
9554
10919
R410A
220~240V
~
1Ph~50Hz
GMVL-R28Zd/Na-K /
GMV-R36Zd/Na-K
12284
13649
GMVL-R36Zd/Na-K /
GMV-R50Zd/Na-K
17061
19790
GMVL-R50Zd/Na-K /
GMV-R71Zd/Na-K
24226
27297
GMVL-R71Zd/Na-K /
GMV-R90Zd/Na-K
30709
34121
GMVL-R90Zd/Na-K /
GMV-R112Zd/Na-K
38216
42652
GMVL-R112Zd/Na-K /
GMV-R125Zd/Na-K
42652
46064
GMVL-R125Zd/Na-K /
Conversion Formula: Btu/h=kW×3412
Notes:
① Cooling only unit (GMVL type) has no items on heating;
② Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of
ambient;
③ Nominal capacities are based on the following conditions:
Cooling Heating
Indoor :27℃(80.6℉)/19℃(66.2℉)
Outdoor: 35℃(95℉)/-
Indoor: 20℃(68℉)/-
Outdoor : 7℃(44.6℉)/6℃(42.8℉)
1.3 Hydro-box
Model Capacity(kW) Appearance
RQD5GA-K
RQD5GB-K
RQ5GB-K
5
RQD8GA-K
RQD8GB-K
RQ8GB-K
8
RQD20LA-M 20
RQ20LA-K 20
RQD30LA-M 30
RQ30LA-K 30
Note:
① Select the model of hydro-box based on suggestions of the professional and local weather conditions.
② The data in the tables is subject to change so the data on the nameplate shall govern.
