Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
10
1.4 Water Tank
Model
Capacity
(L)
Appearance
SXD250LC-K 250
SXD300LC-K 300
SXD350LC-K 350
SXD400LC-K 400
SXVD200LCJ/A-K 200
SXVD300LCJ/A-K 300
SXVD350LCJ/A-K 350
SXVD400LCJ/A-K 400
SXVD200LCJ2/A-K 200
SXVD300LCJ2/A-K 300
SXVD350LCJ2/A-K 350
SXVD400LCJ2/A-K 400
Note:
① Select the capacity of water tank based on suggestions of the professional and local weather conditions.
② The data in the tables is subject to change so the data on the nameplate shall govern.
