Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
12
2.3 Nomenclature of Hydro-box
RQ D 5 G A
□
1 2 3 4 5 6
S/N Description Options
1
Product Code : Hydro-box
2
Fuction Code
D－Electric heating，Default－No electric heating
3
Heat Exchage Capacity
Rated heat exchange capacity of hydro-box, and unit
is KW
4 Structure Code
G－Wall-mounting;L－Stand;W－Horizontal
5
Design S/N
Range it according to A.B.C…(omited when first
design)
6
Power Supply Specification
M: 380-415V-3Ph-50Hz K: 220-240V-1Ph-50Hz
2.4 Nomenclature of Water Tank
SX
□ □
300 L C
□ □
1 2 3 4 5 6 7 8
S/N Description Options
1 Assy Code SX-Water Tank
2 Water Tank Type
V-Heat pump water tank for VRF units;Default－Common
heat pump water tank
3 Fuction Code
D － Heating(with electricity);Default － Heating(without
electricity)
4
Water Tank
Capacity
Water tank Capacity; unit：（L）
5 Structure
B－Wall-mounting，L－Stand
6 Bearing or not
C－Bearing,Default－No bearing
7 Coil Type
J－Inner static heating ;JW－Outer static heating
D－Coil for floor heating;Default－No heat exchange tube
8
Power complement M: 380-415V-3Ph-50Hz K: 220-240V-1Ph-50Hz
