Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
311
No. Part Name
GMV(L)-R90P/Na-K,GMV(L)-R100P/Na-K,
GMV(L)-R112P/Na-K,GMV(L)-R125P/Na-K,
GMV(L)-R140P/Na-K
Code Qty.
1 Top Cover Sub-assy
01258606 1
2 Hook
02118504 2
3 Left Side Seal-hole Plate Sub-assy
01308673 1
4 Seal of Connection Pipe
01498601 1
5 Electric Box Assy
01394602 1
6 Left Side Plate Sub-assy
01308676 1
7 Left Support of Evaporator
01078603 1
8 Liquid-entered Pipe Sub-assy
03338802 1
9 Collect Gas Pipe Sub-assy
04674608 1
10 Evaporator Sub-assy
01038624 1
11 Fan Fixed Plate Sub-assy
01338630 1
12 Motor FG75B
15018613 1
13 Fan Motor (Left)SYP-200/190J-1
15018603 2
14 Return air inlet side-board Sub-assy
01499066 1
15 Motor FG150B
15018612 1
16 Fan motor (Right)SYP-200/190J-1
15018604 1
17 Bottom Cover Assy
01258603 1
18 Cover of Air-in
01258602 1
19 Water Tray Assy
01278603 1
20 Right Side Plate Sub-assy
01308677 1
21 Hook
02118504 2
22 Left Support of Evaporator
01078604 1
23 Return air inlet Sub-assy
01498608 1
