Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
41
4.4 Hydro-box
Model RQD5GA-K RQD8GA-K
Heat Exchange
Capacity
kW 5 8
Power Supply - 220V 50Hz 220V 50Hz
Water Pump
Input Power 80W 80W
Water Flow
1
m
3
/h 1 m
3
/h
Delivery Lift 6m 6m
Heat Exchanger -
Tube in tube Tube in tube
Water System
Connection
Caliber of water-in/out
pipe
3/4"in 3/4"in
Screw Thread G3/4 G3/4
Fluorin Systen
Connection
Gas Pipe Φ16mm Φ16mm
Liquid Pipe Φ12.7mm Φ12.7mm
Dimensions (mm) （H×W×D） 650×300×250 650×300×250
Model RQD5GB-K RQD8GB-K
Heat Exchange
Capacity
kW 5 8
Power Supply - 220V 50Hz 220V 50Hz
Water Pump
Input Power 80W 80W
Water Flow 4.4GPM 4.4GPM
Delivery Lift 6m 6m
Heat Exchanger -
Tube in tube Tube in tube
Water System
Connection
Caliber of water-in/out
pipe
3/4"in 3/4"in
Screw Thread G3/4 G3/4
Fluorin Systen
Connection
Gas Pipe Φ15.9mm Φ15.9mm
Liquid Pipe Φ12.7mm Φ12.7mm
Dimensions (mm) （H×W×D） 650×435×258 650×435×258
Model RQ5GB-K RQ8GB-K
Heat Exchange
Capacity
kW 5 8
Power Supply - 220V 50Hz 220V 50Hz
Water Pump
Input Power 80W 80W
Water Flow 4.4GPM 4.4GPM
Delivery Lift 6m 6m
Heat Exchanger -
Tube in tube Tube in tube
Water System
Connection
Caliber of water-in/out
pipe
3/4"in 3/4"in
Screw Thread G3/4 G3/4
Fluorin Systen
Connection
Gas Pipe Φ15.9mm Φ15.9mm
Liquid Pipe Φ12.7mm Φ12.7mm
Dimensions (mm) （H×W×D） 650×300×250 650×300×250
