![Gree HOME GMV [46/367] Tube in tube tube in tube tube in tube tube in tube](/img/pdf.png)
Gree HOME GMV [46/367] Tube in tube tube in tube tube in tube tube in tube
![Gree HOME GMV [46/367] Tube in tube tube in tube tube in tube tube in tube](/views2/1052459/page46/bg2e.png)
Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
42
Model RQ20LA-K RQD20LA-M RQ30LA-K RQD30LA-M
Heat
Exchange
Capacity
kW 20 20 30 30
Power
Supply
- 220V 50Hz 380V 50Hz 220V 50Hz 380V 50Hz
Water
Pump
Input Power 370W 370W 370W 370W
Water Flow 2.5m
3
/h 2.5m
3
/h 2.5m
3
/h 2.5m
3
/h
Delivery Lift 15m 15m 15m 15m
Heat
Exchanger
-
Tube in tube Tube in tube Tube in tube Tube in tube
Water
System
Connection
Caliber of
water-in/out
pipe
3/4"in 3/4"in 3/4"in 3/4"in
Screw
Thread
G3/4 G3/4 G3/4 G3/4
Fluorin
Systen
Connection
Gas Pipe Φ19.05mm Φ19.05mm Φ19.05mm Φ19.05mm
Liquid Pipe Φ15.9mm Φ15.9mm Φ15.9mm Φ15.9mm
Dimensions (mm)
（H×W×D）
1050×410×905 1050×410×905 1050×410×905 1050×410×905
