Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
17
Model GMV(L)-R45P/Na-K GMV(L)-R50P/Na-K GMV(L)-R56P/Na-K
Cooling Capacity
kW 4.5 5.0 5.6
Btu 15355 17061 19108
Heating Capacity
kW 5.0 5.8 6.3
Btu 17060 19790 21496
Air Flow Rate
m3/h 840 840 1400
CFM 494 494 824
Sound Pressure Level (H/L) dB(A) 40/36 40/36 42/38
External Static Pressure Pa 40 40 100
Power Supply 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz
Fan Motor
Output kW 0.07 0.07 0.15
Running
Current
A 0.69 0.69 1.32
Connectin
g Pipes
Gas Pipe
mm
φ12.7 φ12.7 φ15.9
inch
φ1/2＂ φ1/2＂ φ5/8＂
Liquid Pipe
mm
φ6.35 φ6.35 φ9.52
inch
φ1/4＂ φ1/4＂ φ3/8＂
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
（External Dia. × Thickness）
mm φ30×1.5 φ30×1.5 φ30×1.5
Unit Dimensions(W×D×H) mm 980×736×266 980×736×266 1112×756×300
Package Dimensions
(W×D×H)
mm 1068×766×320 1068×766×320 1245×785×360
Weight（Net/Gross） kg 36/39 36/39 55/59
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the
cooling only units does not have any parameters of performing heating;
③ The sound level is tested under circumstance of semi-anechoic chamber; the value of noise could be a
little higher in actual operation.
