Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
18
Model GMV(L)-R63P/Na-K GMV(L)-R71P/Na-K GMV(L)-R80P/Na-K
Cooling Capacity
kW 6.3 7.1 8.0
Btu 21496 24226 27297
Heating Capacity
kW 7.0 8.0 8.8
Btu 23884 27296 30026
Air Flow Rate
m3/h 1400 1400 1400
CFM 824 824 824
Sound Pressure Level (H/L) dB(A) 42/38 42/38 42/38
External Static Pressure Pa 100 100 100
Power Supply 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz
Fan Motor
Output kW 0.15 0.15 0.15
Running
Current
A 1.32 1.32 1.32
Connectin
g Pipes
Gas Pipe
mm
φ15.9 φ15.9 φ15.9
inch
φ5/8 φ5/8 φ5/8
Liquid Pipe
mm
φ9.52 φ9.52 φ9.52
inch
φ3/8 φ3/8 φ3/8
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
External Dia. × Thickness
mm φ30×1.5 φ30×1.5 φ30×1.5
Unit Dimensions(W×D×H) mm 1112×756×300 1112×756×300 1112×756×300
Package Dimensions
(W×D×H)
mm 1245×785×360 1245×785×360 1245×785×360
WeightNet/Gross kg 55/59 55/59 55/59
Notes:
Refer to the product nameplate for parameters and specification of the unit;
The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the
cooling only units does not have any parameters of performing heating;
The sound level is tested under circumstance of semi-anechoic chamber; the value of noise could be a
little higher in actual operation.
