Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
19
Model GMV(L)-R90P/Na-K
GMV(L)-R100P/Na-
K
GMV(L)-R112P/Na-
K
Cooling Capacity
kW 9.0 10.0 11.2
Btu 30709 34121 38216
Heating Capacity
kW 10.0 11.0 12.5
Btu 34120 37532 42650
Air Flow Rate
m3/h 2000 2000 2000
CFM 1177 1177 1177
Sound Pressure Level (H/L) dB(A) 44/40 44/40 44/40
External Static Pressure Pa 100 100 100
Power Supply 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz
Fan Motor
Output kW 0.225 0.225 0.225
Running
Current
A 2.14 2.14 2.14
Connectin
g Pipes
Gas Pipe
mm
φ15.9 φ15.9 φ15.9
inch
φ5/8＂ φ5/8＂ φ5/8＂
Liquid Pipe
mm
φ9.52 φ9.52 φ9.52
inch
φ3/8＂ φ3/8＂ φ3/8＂
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
（External Dia. × Thickness）
mm φ30×1.5 φ30×1.5 φ30×1.5
Unit Dimensions(W×D×H) mm 1385×736×300 1385×736×300 1385×736×300
Package Dimensions
(W×D×H)
mm 1514×795×360 1514×795×360 1514×795×360
Weight（Net/Gross） kg 75/79 75/79 75/79
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the
cooling only units does not have any parameters of performing heating;
③ The sound level is tested under circumstance of semi-anechoic chamber; the value of noise could be a
little higher in actual operation.
