Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
20
Model GMV(L)-R125P/Na-K GMV(L)-R140P/Na-K
Cooling Capacity
kW 12.5 14.0
Btu 42652 47770
Heating Capacity
kW 13.5 15.0
Btu 46060 51180
Air Flow Rate
m3/h 2000 2000
CFM 1177 1177
Sound Pressure Level (H/L) dB(A) 44/40 45/41
External Static Pressure Pa 100 50
Power Supply 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz
Fan Motor
Output kW 0.225 0.225
Running Current A 2.14 2.14
Connecting
Pipes
Gas Pipe
mm
φ15.9 φ15.9
inch
φ5/8＂ φ5/8＂
Liquid Pipe
mm
φ9.52 φ9.52
inch
φ3/8＂ φ3/8＂
Connection Method Flare Connection Flare Connection
Drain Pipes
（External Dia. × Thickness）
mm φ30×1.5 φ30×1.5
Unit Dimensions(W×D×H) mm 1385×736×300 1385×736×300
Package Dimensions
(W×D×H)
mm 1514×795×360 1514×795×360
Weight（Net/Gross） kg 75/79 75/79
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the
cooling only units does not have any parameters of performing heating;
③ The sound level is tested under circumstance of semi-anechoic chamber; the value of noise could be a
little higher in actual operation
