Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
21
Model
GMV(L)-R22P/NaB-
K
GMV(L)-R28P/NaB-K GMV(L)-R36P/NaB-K
Cooling Capacity
kW 2.2
2.8
3.6
Btu 7507 9554 12284
Heating Capacity
kW 2.5
3.2
4.0
Btu 8530 10918 13648
Air Flow Rate
m3/h 450 570 570
CFM 265
335
335
Sound Pressure Level (H/L) dB(A) 37/33 39/35 39/35
External Static Pressure Pa 50/20 50/20 50/20
Power Supply 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz
Fan
Motor
Output kW 0.04 0.06 0.06
Running
Current
A 0. 28 0.41 0.41
Connecti
ng Pipes
Gas Pipe
mm
φ9.52
φ9.52 φ12.7
inch
φ3/8＂
φ3/8＂ φ1/2＂
Liquid Pipe
mm φ6.35
φ6.35 φ6.35
inch
φ1/4＂ φ1/4＂ φ1/4＂
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
（External Dia. ×
Thickness）
mm φ20×1.5 φ20×1.5 φ20×1.5
Unit Dimensions(W×D×H) mm
880×655×250 880×655×250 880×655×250
Package Dimensions
(W×D×H)
mm
1020×745×305 1020×745×305 1020×745×305
Weight（Net/Gross） kg 27/31 28.5/33.5 28.5/33.5
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the
cooling only units does not have any parameters of performing heating;
③ The sound level is tested under circumstance of semi-anechoic chamber; the value of noise could be a
little higher in actual operation.
