Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
28
Model GMV(L)-R28T/Na-K GMV(L)-R36T/Na-K GMV(L)-R45T/Na-K
Cooling Capacity
kW
2.8
3.6 4.5
Btu 9550 12280 15360
Heating Capacity
kW
3.2
4.0 5.0
Btu 10900 13650 17060
Air Flow Rate
m3/h 680 680 680
CFM
400
400 400
Sound Pressure Level (H/L) dB(A) 37/34 37/34 37/34
External Static Pressure Pa / / /
Power Supply 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz
Fan Motor
Output kW 0.035 0.035 0.035
Running
Current
A 0.19 0.19 0.28
Connectin
g Pipes
Gas Pipe
mm Φ9.52 Φ12.7 Φ12.7
inch Φ3/8 Φ1/2 Φ1/2
Liquid Pipe
mm Φ6.35 Φ6.35 Φ6.35
inch Φ1/4 Φ1/4 Φ1/4
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
（External Dia. × Thickness）
mm Φ30×1.5 Φ30×1.5 Φ30×1.5
Unit Dimensions
(W×D×H)
mm
Main body：840×840×190 Panel：950×950×60
Package Dimensions
(W×D×H)
mm
Main body：960×960×257 Panel：1040×1025×115
Net Weight
(Main body/Panel)
kg 25/6.5
Gross Weight
(Main body/Panel)
kg 33/10
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the
cooling only units does not have any parameters of performing heating;
③ The sound level is tested under circumstance of semi-anechoic chamber; the value of noise could be a
little higher in actual operation.
