Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
26
Model GMV(L)-R90PS/NaB-K GMV(L)-R112PS/NaB-K GMV(L)-R140PS/NaB-K
Cooling Capacity
kW 9.0 11.2 14.0
Btu 30709 38216 47770
Heating Capacity
kW 10.0 12.5 15.0
Btu 34120 42650 51180
Air Flow Rate
m3/h 1700 1700 2000
CFM 1001 1001 1177
Sound Pressure Level
(H/L)
dB(A)
48/44 48/44 50/46
External Static Pressure Pa 80/40 80/40 100/50
Power Supply 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz
Fan
Motor
Output kW 0.225 0.225 0.26
Running
Current
A 2.15 2.15 2.67
Conn
ecting
Pipes
Gas Pipe
mm Φ15.9 Φ15.9 Φ15.9
inch 5/8＂ 5/8＂ 5/8＂
Liquid Pipe
mm Φ9.52 Φ9.52 Φ9.52
inch 3/8＂ 3/8＂ 3/8＂
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
（External Dia. ×
Thickness）
mm Φ30×1.5 Φ30×1.5 Φ30×1.5
Unit Dimensions
(W×D×H)
mm
1425×736×300 1425×736×300 1425×736×300
Package Dimensions
(W×D×H)
mm
1514×785×360 1514×785×360 1514×785×360
Weight（Net/Gross） kg 64/73 64/73 65.5/75
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the
cooling only units does not have any parameters of performing heating;
③ The sound level is tested under circumstance of semi-anechoic chamber; the value of noise could be a
little higher in actual operation.
