Dc Inverter VRF plus Water Heater Solution Service Manual INSTALLATION
177
CAUTION:
Never let the pipe in direct contact with the fixing metal parts. Thermal insulation shall be
provided around the fixing metal parts; otherwise, condensing will occur.
2）Fixing of vertical pipe
The vertical pipe may be fixed by using the commodity tools in market or self-made tools. As
above, the fixing point shall also be thermally insulated.
3）Fixing of other points
Measures shall be taken to prevent the extension or shrinkage of pipes from causing excessive
loads to some positions, machine joint and waterproof points. Generally, such positions refer to the
branch pipe joint, pipe ends, four sides of indoor unit and wall-cross hole.
10.5 Management and Machining of Refrigerant Piping
1）Storage
After receiving the refrigerant pipe and other components, do not move them to the storage
until confirming that they have no deformation, bend, crack or damage.
The pipe end must be sealed to prevent the invasion of moisture or wastes.
The copper pipe with coating may become deformed under the compression of the coating
material, so that the coils shall be placed upright.
To avoid the invasion of moisture or wastes, a support higher than the ground must be built
by using woods.
Care of pipe end during construction
The pipe ends must be well cared during construction. According to the working position, work
progress and surrounding environment, the most effective way is to seal the end and wrap with
adhesive tape.
i. Sealing method
Clamp the pipe end to flat and weld on the clearance. Then, charge nitrogen 2～
5kgf/cm
2
. This will be more effective.
ii. Method for wrapping with adhesive tape
Seal the pipe end with ethylene tape.
2）Coil unwinding
CAUTION:
When unwinding the coil, take care not to drag it on the ground. The coil shall be slowly
unwound on ground without any twisting. In case of excessive compression by any
hard object during unwinding, the thermal insulation materials may be damaged and
cannot be recovered, which will deteriorate the performance of thermal insulation. Do
not unwind carelessly. Otherwise, the fitting pipe might be flattened.
The copper pipe shall be rounded if the pipe end is deformed.
(The higher the size, the higher the possible deformation)
3）Measuring of pipe
(To reduce the resistance and length of copper pipe), the dimension of main refrigerant pipe
shall be so taken that the bends shall be minimized, the radius of bend section shall be
increased and the upstream and downstream section shall be reduced. Use the method that
can reduce the actual length and equivalent length of the copper pipe.
Sometimes the connection pipe of indoor unit must be adjusted due to the relation with
accessories, drainage pipe and connection surface. Therefore, a fairly marginal dimension
shall be taken.
Clamp the pipe end and weld on it.
