Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
224
F4
Outdoor
ambient
temperature
sensor error
Outdoor
environment
sensor
Test for 30 seconds successively to check if the temperature
sensor is disconnected. If yes, alarm will be sent; otherwise no
processing will be made. If the controller of outdoor unit detects
failure of outdoor sensor under open circuit, short circuit and
excess of test value, the outdoor unit will execute the following
default actions, that is, the error message will be sent to each
indoor unit and the error code will be displayed via error indicator
or wired controller. When the outdoor ambient temperature is
lower than -5 , the disconnection failure of outdoor inlet, middle ℃
and exit sensors in shield room will be processed as under -30 .℃
F7
Outdoor defrost
temperature
sensor error
Outdoor
Defrost Sensor
Test for 30 seconds successively to check if the temperature
sensor is disconnected. If yes, alarm will be sent; otherwise no
processing will be made. If the controller of outdoor unit detects
failure of outdoor sensor under open circuit, short circuit and
excess of test value, the outdoor unit will execute the following
default actions, that is, the error message will be sent to each
indoor unit and the error code will be displayed via error indicator
or wired controller. When the outdoor ambient temperature is
lower than -5 , the disconnection failure of outdoor inlet, middle ℃
and exit sensors in shield room will be processed as under -30 .℃
F9
Exhaust
temperature
sensor error
Exhaust
temperature
sensor
Test for 30 seconds successively to check if the temperature
sensor is disconnected. If yes, alarm will be sent; otherwise no
processing will be made. If the controller of outdoor unit detects
failure of outdoor sensor under open circuit, short circuit and
excess of test value, the outdoor unit will execute the following
default actions, that is, the error message will be sent to each
indoor unit and the error code will be displayed via error indicator
or wired controller. When the outdoor ambient temperature is
lower than -5 , the disconnection failure of outdoor inlet, middle ℃
and exit sensors in shield room will be processed as under -30 .℃
Error Code of Hydro Unit
Error Code Error
C5 Jumper error
E6 Communication error
F9 Outlet water temperature sensor error
F8 Inlet water temperature sensor error
FL Water temperature sensor error
L7 Current switch error/lack water protecting
EH Floor auxiliary heater felt protecting
LP
Outdoor unit board and Hydro unit board are not
matching
Error Code of Duct-type Unit
Error
Error
Code
Error
Error
Code
Prevention against low temperature E2
Error with oil temperature
sensor 2 (digital)
Fb
Outdoor ambient temperature sensor error F4
Indoor ambient temperature
sensor error
F0
Indoor tube-inlet sensor error F5 Exhaust overtemperature E4
Outdoor tube-middle sensor error F6 Low-pressure protection E3
Outdoor tube-exit sensor error F7 Overcurrent Protection E5
Error with exhaust temperature sensor 1
(fixed-frequency)
F8 High-pressure protection E1
