Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
289
★ GMV-Pds140W/Na-K, GMV-Pds160W/Na-K Exploded View
24 Filter φ19 07210037 1
25 4-way valve sub-assy2 04144166 1
26 4-way valve(3.5 HP)(R410A) 4300008201 1
27 4-way valve fittings( solenoid coil ) 4300040031 1
28 Rear side plate 01314168P 1
29 Handle 26235253 3
30 Cut-off valve 3/8(R410A) 07130209 1
31 Cut-off valve 1/2(R410A) 07130210 1
32 Cut-off valve 3/4(R410A) 07130212 1
33 Gas valve sub-assy 07103030 1
34 Valve support assy 01804156P 1
35 One-way valve 04324001 1
36 Filter 07212121 2
37 Electric expansion valve sub-assy2 07334337 1
38 Electric expansion valve SPF-18D88 07334193 1
39 Electric expansion valve coil 4300010811 1
40 Solenoid Valve fittings (Solenoid Coil) 4304000428 1
41 Solenoid Valve FDF6A 43000072 1
42 Oil Separator 07228302 1
43 Oil SeparatorSub-assy 07424136 1
44 Liquid Accumulator (with 3 pipes 07424135 1
45 Pressure Switch (with leading-out wire) 4602000902 1
46 Discharge Pipe Sub-assy 04634235 1
47 PFCInductance 43120122 1
48 Mounted Plate Sub-assy 01844134P 1
49 Compressor and Fittings 5VD420ZAA21 00205224 1
50 Isolation sheet sub-assy2 01244136 1
51 Inductance Box 01424173 1
52 Chassis Sub-assy 01194137P 1
53 Motor SWZ120A 15704115 1
54 Axial Flow Fan φ472X165 10338731 1
55 Electric expansion valve sub-assy 07334346 1
56 Electric expansion valve VPF-25D18 07334102 1
57 Electric expansion valve coil 4300010810 1
58 Cabinet 01435436 1
69 Front Side PlateSub-assy 01314139 1
60 Front Grill 22414102 2
