Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
297
Parts List:
Notes
：
① is only the part of RQ5GB-K
；
② is only the part of RQ8GB-K
；
No. Part Name Code Qty
1
Top Cover
01262817P 1
2 Electric Box Cover 01424256P 1
3
Main Board
30226228 1
4 Electric Box Assy
01395079 ①
1
01395080 ②
5 Column 01854113P 2
6
Supporter 1
01802828 1
7 Right Side Plate Sub-Assy 01312810P 1
8
Handle
26235253 2
9 Double Pipe Condenser
01152802①
1
01152804②
10 Support sub-assy 01802830P 1
11 Rear Panel 02222812P 2
12 Supporting Strip 1 01892828P 4
13 Chassis Sub-assy 01192808P 1
14 Supporter 01802826P 1
15 Cut-off valve Sub-Assy 2 07332811 1
16 Cut-off valve Sub-Assy 1 07332810 1
17 Left Side Plate Sub-Assy 01312809P 1
18 Pipe connector 06652805 1
19 Outlet Water Pipe Sub-Assy
04364105①
1
04362831 ②
20 Supporter 01802827P 1
21 Enter Water Pipe Sub-Assy 04362830 1
22 Water Pump 43130322 1
23 Terminal Board 42010265 1
24 Transformer 43110233 1
25 Auto Air Outlet Valve 07108208 1
26 Temperature Sensor 390002073 1
27 Display Board 30296313 1
28 Tube sensor 39000283 1
29 Tube sensor 390000372 1
