Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
299
Parts List:
Notes
：
① is only the part of RQD5GB-K
；
② is only the part of RQD8GB-K
；
No. Part Name Code Qty
1 Top Cover 01264216P 1
2 Electric Box Cover 01424268P 1
3 Original PCB Mounting Plate Sub-Assy 01324367 1
4 Electric Box Assy 01392868 1
5 Panel front(rear) 01544141P 2
6 Enter Water Pipe Sub-Assy 04362830 1
7 Water Pump 43130322 1
8 Water Flow Switch Sub-Assy 45028061 1
9 Double Pipe Condenser
01152802①
1
01152804②
10 Tube in tube heat exchanger
01124184①
1
00904122 ②
11 Left Side Plate Sub-Assy 01314242P 1
12 Supporter 01802827P 1
13 Outlet Water Pipe Sub-Assy 04364119 1
14 Cut-off valve Sub-Assy 2 07334418 1
15 Cut-off valve Sub-Assy 1 07334419 1
16 Supporter 01802826P 1
17 Cut-off valve 07334422 1
18 Sewage Pipe 04362899 1
19 Chassis Sub-assy 01194145P 1
20 Support sub-assy 01802830P 1
21 Electric heater 32102803 1
22 Column 01854116P 2
23 Terminal Board 42010265 1
24 Main Board 30226228 1
25 AC contactor 44010221 1
26 Transformer 43110233 1
27 Handle 26235253 2
28 Right Side Plate Sub-Assy 01314245P 1
29 Auto Air Outlet Valve 07108208 1
30 Display Board 30296313 1
31 Temperature Sensor 390000372 1
32 Tube sensor 390002073 1
33 Tube sensor 39000283 1
34 Bipolar Air Switch 45010029 1
