Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
301
Parts List:
No. Part Name Code Qty
1
Right Side Plate
01314302P 1
2
Front Panel
01544606P 1
3
Discharge PipeSub-assy
04364103 1
4
Auto Air Outlet Valve
07108208 1
5
Auxiliary Electric Heater DR5
320101091 1
6
Tube-in-tube Connecting PipeSub-assy
05025171 1
7
Check Valve(DN20)
07382807 1
8
Feed Pipe(electric heating)
04364102 1
9
Feed PipeSub-assy
04364101 1
10
Water Pump MHI202(single-phase)
43138218 1
11
Valve Sub-assy(liquid side)
07304121 1
12
Valve Sub-assy(gas side)
07304120 1
13
water flow switch FSF50P-2R1/2
45028207 1
14
Discharge PipeSub-assy
04364107 1
15
expansion drum
072282191 1
16
Support(expansion drum)
01804355P 1
17
SupportSub-assy
01804356P 1
18
ChassisSub-assy
01194139P 1
19
package base frame(wooden)
50232840 1
20
Right Side Plate
01314221P 1
21
Rear Panel
01544605P 1
22
Tube-in-tube condensator
01152807 1
23
Cross Beam Sub-assy
01874182P 2
24
Handle(apricot-gray)
26235253 4
25
Electric box Assy RQ30LA
01394958 1
26
Mains Transformer 48X26G
43110233 1
27
AC contactorCJX9B-25S/D
44010245 1
28
Mainboard Z6P30A
30226228 1
29
Leakage Switch PFIM-40/4/003
45010028 1
30
AC contactorLC1D25M7C
44010213 1
31
Electric box cover
01424317P 1
32
Top cover plate
01264175P 1
