Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
305
No. Part Name
GMV(L)-R22P/Na-K,G
MV(L)-R25P/Na-K
GMV(L)-R28P/Na-K,GMV(L)-R32
P/Na-K,GMV(L)-R36P/Na-K
Code Qty. Code Qty.
1
Top Cover Sub-assy
01259052 1 01259052 1
2
Hook
02112446 2 02112446 2
3
Seal of Left Side Plate
Sub-assy 01499051 1 01499051 1
4
Seal of Connection Pipe
Sub-assy 01499053 1 01499053 1
5
Electric Box Assy
01408739 1 01394605 1
6
Left Side Plate Sub-assy
01308788 1 01308788 1
7
Left Support of Evaporator
01078774 1 01078774 1
8
Liquid-entered Pipe
Sub-assy 03334601 1 03338810 1
9
Collect Gas Pipe Sub-assy
01305018 1 04674609 1
10
Evaporator Sub-assy
01038785 1 01038786 1
11
Fan Fixed Plate Sub-assy
01339095 1 01339095 1
12
Centrifugal fan
10319051 1 10319051 1
13
Return air inlet side-board
Sub-assy 01499055 1 01499055 1
14
Motor
15019053 1 15019522 1
15
Centrifugal fan
10319051 1 10319051 1
16
Bottom Cover
01259086 1 01259086 1
17
Cover of Air-in
01259056 1 01259056 1
18
Water Tray Assy
01279051 1 01279051 1
19
Right Side Plate Sub-assy
01309055 1 01309055 1
20
Hook
02112446 2 02112446 2
21
Left Support of Evaporator
01079056 1 01079056 1
22
Return air inlet side-board
Sub-assy 01498783 1
01498783 1
