Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
307
No. Part Name
GMV(L)-R40P/Na-K,GMV(L)-R45P/Na-K,GMV(L)-R50P/Na-K
Code Qty.
1 Top Cover Sub-assy
01259064 1
2 Hook
02112446 2
3 Seal of Connection Pipe 2
01498644 1
4 Seal of Connection Pipe 1
01498604 1
5 Electric Box Assy
01404688 1
6 Left Side Plate Sub-assy
01308668 1
7 Left Support of Evaporator
01078629 1
8
Liquid-entered Pipe
Sub-assy 04324601 1
9 Collect Gas Pipe Sub-assy
04674601 1
10 Evaporator Sub-assy
01038623 1
11 Fan Fixed Plate Sub-assy
01339058 1
12 Centrifugal fan
10319051 1
13 Return air inlet Sub-assy
01499061 1
14 Motor FG70B
15018322 1
15 Centrifugal fan
10319051 1
16 Bottom Cover
01258649 1
17 Cover of Air-in
01258650 1
18 Water Tray Sub-assy
01278633 1
19 Right Side Plate Sub-assy
01308670 1
20 Hook
02112446 2
21 Left Support of Evaporator
01078625 1
22 Return air inlet Sub-assy
01498641 1
