Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
309
No. Part Name
GMV(L)-R56P/Na-K,GMV(L)-R63P/Na-K,GM
V(L)-R71P/Na-K,GMV(L)-R80P/Na-K
Code Qty.
1 Top Cover Sub-assy
01258652 1
2 Hook
02118504 2
3 Left Side Seal-hole Plate Sub-assy
01308680 1
4 Seal of Connection Pipe
01498610 1
5 Electric Box Assy
01394609 1
6 Left Side Plate Sub-assy
01308676 1
7 Left Support of Evaporator
01078603 1
8 Liquid-entered Pipe Sub-assy
04324603 1
9 Collect Gas Pipe Sub-assy
04674602 1
10 Evaporator Sub-assy
01054601 1
11 Fan Fixed Plate Sub-assy
01338631 1
12 Fan Motor (Left)SYP-200/190J-1
15018603 1
13 Return air inlet side-board Sub-assy
01499074 1
14 Motor FG150B
15018612 1
15 Fan motor (Right)SYP-200/190J-1
15018604 1
16 Bottom Cover
01258612 1
17 Cover of Air-in
01258614 1
18 Water Tray Assy
01278612 1
19 Right Side Plate Sub-assy
01308677 1
20 Hook
02118504 2
21 Left Support of Evaporator
01078604 1
22 Return air inlet Sub-assy
01498612 1
