Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
319
No
Part Name
Code
Qty
GMVL-R56P/NaB-K GMVL-R71P/NaB-K
1 Side Plate of Air outlet
01499074
1 1
2 Left Support of Evaporator
01078603
1 1
3 Evaporator Assy
01024221
1 1
4 Electric expand valve fitting
43040001
1 1
5 Right Support of Evaporator
01078604
1 1
6 Left Side Plate Sub-assy
01315255
1 1
7 Seal of left side Plate Sub-assy
01308680
1 1
8
Seal of left Connection Pipe
Sub-assy
01498610
1 1
9 Hook
02112466
4 4
10 Electric Box Cover
01425249
1 1
11 Top Cover Board Assy
01258651
1 1
12
Right Side Plate Sub
-assy
01308679
1 1
13 Motor Support
01708502
1 1
14 Fan Motor
1570521101
1 1
15 Motor Sub-assy
15018603
1 1
15018604
1 1
16
Border Plate Assy of Air Retur
n
End
01499074
1 1
17 Filter
11129066
1 1
18 Electric Box
01394962
1 1
19 Lower Cover Plate Sub-assy
01258612
1 1
20 Fan motor mounting Plate Sub-assy
01338632
1 1
21 Water Pump Assy
15404119
0 0
22 Terminal Border
42011106
1 1
23 Capacitor
33010014
1 1
24 Transformer
43110239
1 1
25 Main Bord
30226167
1 1
26 Connecting Wire
4001039509
1 1
27 Display Bord
30296013
1 1
28 Sensor sub-assy
39004167
1 1
