Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
329
No. Part Name
GMV-R28T/Na-K,GMV-R36T/Na-
K
GMVL-R28T/Na-K,GMVL-R36T/Na-
K
Code Qty. Code Qty.
1
Tube Exit Plate
01382710 1 01382710 1
2
Body Fixed Plate
01332701 4 01332701 4
3 Front Side Plate 01302717 1 01302717 1
4 Left Side Plate 01302740 1 01302740 1
5
Base Plate
01222702 1 01222702 1
6
Rear Side Plate
01302719 1 01302719 1
7 Bottom Foam 52012716 1 52012716 1
8
Motor Gasket
76712711 3 76712711 3
9 Bolt 70212701 3 70212701 3
10
Motor Fixer
01702701 1 01702701 1
11 Fan Motor 15704901 1 15704901 1
12 Centrifugal Fan 10312721 1 10312721 1
13
Evaporator
Connection
01072004 1 01072004 1
14
Cable-cross Loop
76513101 2 76513101 2
15
shunt
072287842 1 072287842 1
16 Water Tray 12412701 1 12412701 1
17 Screw 70140032 4 70140032 4
18
Electric Box Base
Plate
01412721 1 01412721 1
19 Flow Guide Loop 10372701 1 10372701 1
20 Electric Box 20102701 1 20102701 1
21 Wire Clamp 71010102 4 71010102 4
22
Terminal Board
T360B
42011222 1 42011222 1
23 Transformer 43110233 1 43110233 1
24
Electric Box Cover I
20102702 1 20102702 1
25
Electric Box Cover II
20102703 1 20102703 1
26
Main Board
30226316 1 30226316 1
27
Capacitor
33010010 1 33010010 1
28 Rubber plug 76712701 1 76712701 1
29 Evaporator 01038778 1 01038778 1
30
Evaporator Support
01072003 2 01072003 2
31 Nut with Washer M6 70310012 1 70310012 1
32
Bolt subassembly
70210051 1 70210051 1
33
Pipe Pump
PJV-1415
43130324 1 43130324 1
34
Pump Gasket
76712702 3 76712702 3
35
Pump Support
01332001 1 01332001 1
36
Water Level Switch
45010201 1 45010201 1
37
Drainage hose
Pump
05232721 1 05232721 1
38
Right Side Plate
01302710 1 01302710 1
39 Cable-cross Loop 76512702 1 76512702 1
40 Pump Cover 01252710 1 01252710 1
41 Bolt 70212701 3 70212701 3
42
Electronic Expansive
Valve
0713411201 1 0713411201 1
